ND3 Tail Lights

Install the updated ND3 tail lights and ensure correct wiring behavior.

—

Overview

The ND3 came out with a few changes, such as headlights, infotainment system, instrument cluster, etc. They also released with a new set of fully LED tail lights with built in reversing lights.


These tail lights will bolt directly into an ND1/ND2 with no body modification. However, the harness connector has changed from a 6Pin connector to a 8Pin connector. With a very simple harness you can make at home, paired with some load bearing resisters you too can have a nice new set of ND3 tail lights. (Although a very expensive upgrade).

Parts

  • ND3 Left Tail Light: N452-51-160 Tail Light
  • ND3 Right Tail Light: N452-51-150 Tail Light
  • Load-bearing resister (50W, 6Ω, 12V Recommended)
  • Your choice of 6-Pin connector (I use Deutsch)
  • Wire
